AL5NM-PSA Type-N Male Connector, Positive Stop™ for 7/8 in AL5-50 and AVA5-50 cable
MFR: Andrew / Connector
NOTE: FOR AVA5-50 CABLE ONLY. WILL NOT WORK ON AVA5-50FX.
| General Specifications | |
| Interface | N Male |
| Body Style | Straight |
| Brand | HELIAX® | Positive Stop™ |
| Mounting Angle | Straight |
| Electrical Specifications | |
| Connector Impedance | 50 ohm |
| Operating Frequency Band | 0 – 5200 MHz |
| Cable Impedance | 50 ohm |
| 3rd Order IMD, typical | -116 dBm @ 910 MHz |
| 3rd Order IMD Test Method | Two +43 dBm carriers |
| RF Operating Voltage, maximum (vrms) | 707.00 V |
| dc Test Voltage | 2000 V |
| Outer Contact Resistance, maximum | 0.30 mOhm |
| Inner Contact Resistance, maximum | 2.00 mOhm |
| Insulation Resistance, minimum | 5000 MOhm |
| Average Power | 0.6 kW @ 900 MHz |
| Peak Power, maximum | 10.00 kW |
Insertion Loss, typical  |
0.05 dB |
| Shielding Effectiveness | -130 dB |
| Outline Drawing | |
Additional Information
| Featured Product | No |
|---|---|
| Made in the USA | No |
| GTIN | No |
| ISBN | No |
| NATO Stock Number | No |
| Manufacturer Part Number | No |
| Manufacturer | Andrew / Connector |
| Condition | New |
| NOS | No |
| Call For Price | No |
| Manufacturer Name | Commscope |
